Digital signage has become an important part of the marketing strategy for many businesses. It helps to deliver messages and information to the target audience in an interactive and engaging way. However, to set up an effective digital signage network, it is important to have the right hardware. In this article, we will discuss the hardware requirements of digital signage, including the minimum requirements for players, the devices that can be used as screens, and some important considerations when selecting your digital signage hardware.
When it comes to digital signage hardware requirements, there is no broadly applicable solution for the hardware needs. The requirements vary based on the type of digital signage software you are using. However, there are some general minimum requirements that you should consider.
Digital Signage Player
A device that is used to show information on screens is a digital signage player. The minimum hardware requirements for the digital signage player depend on the software you are using. Some popular digital signage software includes Windows, Android, and Fire OS.
The selection of a digital signage player may also depend on the type of content that will be displayed. If the signage requires interactive features such as touch screens or motion sensors, the player should have the necessary inputs to support those features.
In addition, if the signage will be used in a networked environment, the player should have a network port and WiFi capabilities to enable remote management and content updates.
Minimum Hardware Requirement for Windows Based Digital Signage Player
If you are planning to use a Windows-based digital signage player, then the minimum hardware digital signage specs are as follows:
| SPECIFICATION | REQUIREMENT |
|---|---|
| Processor | 2.4 GHz celeron or equivalent |
| RAM | 4GB or more |
| Storage | 64GB or more SSD or HDD |
| Connectivity | Wi-Fi, Bluetooth, and Ethernet |
| Video Output | HDMI or DisplayPort with HDCP 1.4 or later, up to 1080p |
| USB Port | USB 2.0 or later |
| Power | Power supply with a minimum of 5V, 2A output |
| Operating System: | Windows 10 Pro |
Minimum Hardware Requirement for Android Based Digital Signage Player
For Android digital signage hardware, the minimum digital signage hardware requirements list is as follows:
| SPECIFICATION | REQUIREMENT |
|---|---|
| Processor | Quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz (similar or higher) |
| RAM | 2GB or more |
| Storage | 16GB or more internal storage |
| Connectivity | Wi-Fi, Bluetooth, and Ethernet |
| Video Output | HDMI (preferably micro HDMI) |
| USB Port | USB 2.0 or later |
| Input Power | 5V DC, 3A |
Minimum Hardware Requirement for Fire OS Based Digital Signage Player
For Fire OS-based digital signage player, the minimum hardware requirements are as follows:
| SPECIFICATION | REQUIREMENT |
|---|---|
| Processor | Quad-core CPU 1.7GHz, GPU 650MHz (similar or higher) |
| RAM | 1GB or more |
| Storage | 8GB or more internal storage |
| Connectivity | Wi-Fi, Bluetooth 4.1 |
| Video Output | HDMI |
| Power | via micro USB |
| Operating System | Fire OS 5.6.0 or later |
Things to Consider When Choosing Digital Signage Player
Apart from the minimum hardware requirements, the following are the things that need to consider related to digital signage equipment:
Free Hard Drive Space
For optimal performance, it is recommended that digital signage media players have sufficient free hard drive space. A general guideline is to ensure that the player has between 1.5 to 2 times the amount of RAM in free hard drive space. This will enable the media player to operate effectively.
Multiple HDMI Ports
If you want to show the same information on two or more screens, consider getting a digital signage player with multiple HDMI connectors.
GPU Performance
If you plan to play digital signage with 4k resolutions, then consider getting players with high GPU performance.
Outdoor Use
If your goal is to deploy digital signage outdoors in extreme conditions, consider setting up a cloud-based digital signage system solution and having a physical network connection with the digital signage player.
Indoor Use
To play indoor digital signage for only one device forever, considering tiny or stick PCs (like Fire TV stick) is a better way to go since they are extremely compact and simple to maintain.
You can read more about digital signage slayer here!
Now, let’s talk about the next important hardware in Digital Signage, which is the screen!
Digital Signage Screen
With advancements in technology, digital signage screens are becoming more affordable and accessible to businesses of all sizes, making them an attractive option for marketing and communication efforts. Here are some types of digital signage screens:
Monitors
Monitors are one of the most common devices used for Digital Signage. They are usually connected to a computer or media player and display dynamic content such as images, videos, and text. Monitors are available in various sizes and resolutions and can be easily mounted on walls or stands. They are cost-effective and can be used in a variety of settings, usually in small or self-owned stores.
Non-Smart TVs
Non-Smart TVs are traditional televisions that do not have built-in internet connectivity or app support. They are often used for Digital Signage by connecting them to a media player or computer that provides the necessary content. Non-Smart TVs are available in various sizes and are often more affordable than Smart TVs or Professional TVs.
Smart TVs
Smart TVs are televisions with built-in internet connectivity and app support. They can be used for Digital Signage by downloading and installing Digital Signage software or apps. Smart TVs are easy to set up and do not require any additional hardware. They offer a variety of features such as streaming services, web browsing, and social media integration.
Professional TVs
Professional TVs are designed specifically for Digital Signage applications. They offer features such as built-in media players, network connectivity, and remote management capabilities. Professional TVs are available in larger sizes and are built to withstand continuous operation. They are often used in commercial settings such as airports, hotels, and shopping malls.
Conclusion
Ultimately, everything comes down, depending on your use case and cost. When deciding on the digital signage hardware requirements, it’s important to think about the type of devices that can be used as digital signage screens. There are a variety of options available, such as TVs, computer monitors, and specialized digital signage displays. It’s important to consider the specific needs of your business and the environment where the signage will be displayed.
By keeping these things in mind, you can create an effective and efficient digital signage display that will help you communicate with your customers effectively.
